Fan nozzles are ideal for creating bright and sharp lines on your sports field. For optimal results, it's important to set up the fan nozzle correctly both on the robot and in the app. If you haven't already changed your nozzle, please see this guide on how to do so. Once the fan nozzle is installed, follow these steps to ensure it's set up properly. Make sure that the paint canister is full and the robot is ready to paint before beginning.
How to set up a fan nozzle
Position the Spray Tool by Pulling out the spring pin and adjust the robot's spray tool to your desired height.
1. From the home screen on your tablet, tap "Tools".
2. Then tap "Prime pump."
3. Once priming is complete, tap "Test spray", wait for one second, then tap "Stop spray".
4. Measure the width and length of the painted test line and note the dimensions.
5. Tap the gear icon () in the top left corner of your home screen to access the settings menu.
6. Tap "Robot settings," scroll down to the "Paint settings" section, and select "Fan" under "Nozzle."
7. Under "Paint width" and "Paint length," enter the measured dimensions from your test spray.
You're now ready to paint with your fan nozzle!
If you encounter any issues or have trouble changing the nozzle, please contact support. You can find their contact information here.
